Field Cinema Rig for Canon Cinema EOS MKII

Field Cinema Rig for Canon Cinema EOS MKII

SKU: 3-169-0008

Complete your Canon EOS MK II camera by providing the necessary camera plate and cage in a high-quality affordable package.

What's Included

Tech Specs

Buying Guide

Related Products

Canon Cinema EOS MK II

The EOS MK II cage is able to be configured into shoulder rig, handheld rig, and studio configurations.The latest ultraCage Black Professional Series is the support cage designed for the Canon EOS Cinema C100 MK II and C300 MK II digital cinema cameras, and has been called the essential accessory for transforming these great cameras into phenomenal production powerhouses.

C100 MKII and C300 MKII

The ultraCage delivers all the needed features for stability, accessory support, security, and modularity to fulfill the promise of the EOS MK II cameras. The ultraCage delivers professional quality and features and is lightweight and form-fitting. It is completely unobtrusive. All camera displays, buttons, and doors can be accessed without interference. The ultraCage Cinema Bundle is the ultimate rig for studio-style productions where most of the shots have the C100 MKII and C300 MKII on tripod, dolly, or steadicam.

Key Features

  • Configure to your shooting style and adjust your shooting requirements.
  • ultraCage baseplate is designed with the correct height and mounting points for adding the wider 15mm studio offset or 19mm rails.
  • Designed to use either the C100 MKII or C300 MKII camera body with an external monitor or third party EVF.

Tech Specs

  • Several mounting points available
  • Unique top and bottom camera mounting system.
  • Optional backPack - mounting plate cheeseplate includes taps for Anton Bauer, V-mount, and PAG battery plates.
  • Powered cage option - power the camera and camera-top accessories with the exquisitely designed for centralized power conversion, regulation, distribution, and monitoring.

What's Included

  • 1x ultraCage for Canon Cinema MKII. (C100 or C300 MKII)
  • 1x Handlebar Rod Clamp
  • 2x microHandGrip
  • 18" 15mm carbon fiber bottom rails - 1 pair
  • 1x Handlebar 15mm Rod - 4"
  • 1x Handlebar 15mm rod - 8"
  • 1x microShoulderPad with FieldTech™
  • 1x microMount with microSpud (for monitor mounting to handlebar)

Can I add a top handle?

If you would like to place a top handle on your ultraCage, select the Top Handle Option from the configuration. The top handle can be configured both facing forward and backward, allowing for ultimate comfort and balance when holding the rig.

How secure is my camera inside of the ultraCage?

Your Canon C Series Camera is securely latched inside of the ultraCage by four different anchor points. This guarantees your camera will not shift inside of the cage when using even the heaviest of cinema lenses. The points of contact are:

  • Top Bracket Threaded into Integrated ¼”-20 of the Camera
  • 1/4”-20 Thread on the Bottom of the Camera
  • 3/8”-16 Thread on the Bottom of the Camera
  • ”Base-hugging” lip of the baseplate to assure the camera sits straight

    • How do I attach my cage to a tripod?

    The ultraCage for Canon C Series has multiple ¼”-20 and 3/8”-16 on the bottom of the unit, ready to accept any standard tripod or bridge-plate system. You can also utilize the ¼”-20 and 3/8”-16 screws on the bottom of the shoulder pad.

    Can I access all the buttons and features of the camera while it’s in the cage?

    Yes, the ultraCages for C Series cameras do not block any of the ports, buttons, or features of the camera. This includes the Canon Side Grip, which can remain attach to the camera at all times, as well as maintain it’s full range of adjustability.

    Do I need top rails?

    Top rails are valuable components of any rig. You can attach accessories like our microRemote system or monitor and have them travel with you no matter what support you build off of the bottom rails.

    Can I use my existing Redrock Micro gear with this configuration?

    Yes, the ultraCages are modular system and compatible with other Redrock gear.
